9 pin connector for bafang mid motor 9Pin Waterproof Extension Cable for BAFANG

RATINGS/CHARACTERISTICS

  • UL Recognized

  • RoHS Compliant

  • 60 V

  • 9 Pins



NameSmall 9 cores motor cableWaterproof Cable
ModelWYT-P-910AT
Inlet/Outlet9 cores
Rated voltage60V AC/DC
Rated currentPower 15A, signal 2A
Withstand voltage500V
Insulation resistance≥20MΩ
Contact resistance≤10mΩ
Mechanical life200 times
Insertion force≤100N
Pull out force≥50N
Working temperature-25℃~+85℃
Protection gradeIP66
DimensionsMale 12.6mm, female 10mm
Overalllength75mm
Contact element materialgold-plating Copper alloy
Wire specification1.2(1.5)mm²+0.20mm²



RATINGS/CHARACTERISTICS

Waterproof Cable MATERIAL


waterproof Cable Features

Most common signal connector, signal cable for Electric bike.

Lenght: can be any length needed.

Power 15A, signal 2A

Life: 200 times
