Do You Know the Design Advantages of Waterproof Connectors?

Traditional connectors are not waterproof, but with the improvement of waterproof technology, waterproof connectors have begun to be widely used in the field of waterproof wire.Because they are largely unaffected by the environment. Do you know the design advantages of waterproof connectors?

INTEGRATION CABLE 1T3 SPLITTER CABLE FOR EBIKE ELCTRIC SCOOTER

Heat Resistance Performance

Now waterproof connector for high and low temperature have a good adaptability, the highest can reach 200 degrees Celsius (except for a small number of special high temperature waterproof connectors), the lowest can reach minus 65 degrees Celsius.

It is well known that due to the existence of resistance, the equipment will generate a large amount of heat under the working conditions of the current, which will eventually lead to the heating of the equipment.

So we often refer to temperature as the sum of the ambient temperature and the contact temperature.

Because we will indicate the maximum allowable temperature of the rated working current of the waterproof connector, so that the user can better combine the actual situation.

Suitable for Salt Spray Resistant Environments

Waterproof connector can effectively adapt to the environment of salt spray resistance, the general metal structure, contact surface treatment layer may produce electrochemical corrosion, although we can not avoid the working environment with salt and moisture, but we can improve the performance of waterproof connector to prevent the erosion of the equipment.

Therefore, we will do some smoke tests to test the ability of the product, including using the specified concentration of NaCl solution to compress the air to create a smoke atmosphere environment for the equipment, the general waterproof connector can reach more than 48 hours (standard value).

Vibration and Shock Resistance

Vibration and shock resistance is also an important parameter of waterproof connector performance. These two values become increasingly important in special circumstances, including air, space, rail and road transport. These two values are measuring sticks for robustness and electrical contact and reliability of waterproof connectors.

The acceleration, duration of the peak and the time of the impact pulse waveform and electrical connection interruption are often specified in the impact experiment.

Other Features of the Waterproof Connectors

1. Excellent sealing performance. The highest waterproofing rating of the waterproofing connector can reach the IP68 standard.

2. Waterproof connector is an internationally certified product, which has obtained CE certification, low voltage directive and OOHS directive, etc.

These proofs guarantee the quality and irreplaceable market position of waterproof connectors.

3. Various types of waterproof connectors are available.

4. Waterproof connectors are high quality and high design products with water working environment. The equipment is guaranteed to provide customers with a reasonable connection scheme, but also to bring a safe and reliable feeling.

Suzhou Grand Electronic Technology Co., Ltd. is a high-tech enterprise that produces advanced waterproof connectors, welcome to consult!
