Power cable for E bike motor bafang BBS mid motor

Namepower cablePower cable
ModelWYT-P-*095AT
Inlet/Outlet2cores /6 cores
Rated voltage60V AC/DC
Rated currentpower 15A, signal 2A
Withstand voltage500V
Insulation resistance≥20MΩ
Contact resistance≤10mΩ
Mechanical life200 times
Insertion force≤100N
Pull out force≥50N
Working temperature-25℃~+85℃
Protection gradeIP66
DimensionsMale 12.6mm, Female 10mm
Overalllength75mm
Contact element materialgold-plating Copper alloy
Wire specification2.0mm²+0.20mm²

ATINGS/CHARACTERISTICS

MATERIAL


FEATURES

Most common Y splitter connector cable for Electric bike.

Lenght: can be any length needed.

Current: 2A

Life: 200 times

1T3

Waterproof cable: IP65 Sealed waterproof connectors,sturdy and durable

ENVIRONMENTS


TAGS waterproof connector plug suppliermid motor connectorMotor cable motor wiringebike wiring Electric bicycle motor wiring
