| Name | spiral power cable |  |
| Model | WYT-S-*13AT | |
| Inlet/Outlet | 2cores /5 cores | |
| Rated voltage | 48V AC/DC | |
| Rated current | power 20A,signal2A | |
| Withstand voltage | 500V | |
| Insulation resistance | ≥20MΩ | |
| Contact resistance | ≤10mΩ | |
| Mechanical life | 200 times | |
| Working temperature | -25℃～+85℃ | |
| Protection grade | IP66 | |
| Dimensions | 13mm | |
| Overalllength | 96mm | |
| Contact element material | gold-plating Copper alloy | |
| Wire specification | 2.0mm²+0.20mm² |
