Home > Products > Signal Line > M8 Signal cable singla connector UL Recognized RoHS compliant

M8 Signal cable singla connector UL Recognized RoHS compliant

NameM8 Signal lineM8 Signal line
ModelWYT-S-*09AT
Inlet/Outlet2cores~6 cores
Rated voltage48V AC/DC
Rated current2A
Withstand voltage250V
Insulation resistance≥20MΩ
Contact resistance≤10mΩ
Mechanical life200 times
Working temperature-25℃~+85℃
Protection gradeIP66
Dimensions9mm
Overalllength68.9mm
Contact element materialgold-plating Copper alloy
Wire specification0.20mm²

RATINGS/CHARACTERISTICS

MATERIAL


FEATURES

Most common signal connector, signal cable for Electric bike.

Lenght: can be any length needed.

Current: 2A

Life: 200 times


ENVIRONMENTS


TAGS Signal cablesingal wiring
