| Name | M8 signal line |
|
| Model | WYT-P-2-609AT | |
| Inlet/Outlet | 2~6 cores | |
| Rated voltage | 48V AC/DC | |
| Rated current | 2A | |
| Withstand voltage | 250V | |
| Insulation resistance | ≥20MΩ | |
| Contact resistance | ≤10mΩ | |
| Mechanical life | 200 times | |
| Insertion force | ≤80N | |
| Pull out force | ≥30N | |
| Working temperature | -25℃～+85℃ | |
| Protection grade | IP66 | |
| Dimensions | 9mm | |
| overalllength | 62mm | |
| Contact element material | gold-plateing Copper alloy | |
| Wire specification | 0.20mm² |
UL Recognized
RoHS Compliant
48 V
2 to 6 Pins
Most common signal connector, signal cable for Electric bike.
Lenght: can be any length needed.
Current: 2A
Life: 200 times
Ebike throttle, Led dispaly, braker.
Electric scooter throttle, Led dispaly, braker.
signal cable,single connector for electric tools
