Custom Main signal Cable is widely used for the connection of electric bike, Ebike throttle, Led dispaly, braker or single connector for electric tools. The exterior material is safe and waterproof and contact element material is gold-plating copper alloy which is ideal for connection. With UL recognized standard and RoHS compliant, Grand Electronic commits to offer you advanced waterproof cables and related products with best price. Welcome to contact us for a free quotation!
| Name | Main signal cable |  |
| Model | WYT-P-*13AT | |
| Inlet/Outlet | 8~11 cores | |
| Rated voltage | 48V AC/DC | |
| Rated current | 2A | |
| Withstand voltage | 500V | |
| Insulation resistance | ≥20MΩ | |
| Contact resistance | ≤10mΩ | |
| Mechanical life | 200 times | |
| Insertion force | ≤80N | |
| Pull out force | ≥30N | |
| Working temperature | -25℃～+85℃ | |
| Protection grade | IP66 | |
| Dimensions | 13mm | |
| Overalllength | 86mm | |
| Contact element material | gold-plating Copper alloy | |
| Wire specification | 0.20mm² |
UL Recognized
RoHS Compliant
48 V
8 to 11 Pins
MATERIAL
Exterior material: waterproof and durable material
Contact element material: gold-plating Copper alloy
Most common signal connector, signal cable for Electric bike.
Length: can be any length needed.
Current: 2A
Life: 200 times
Ebike throttle, Led dispaly, braker.
Electric scooter throttle, Led dispaly, braker.
signal cable,single connector for electric tools
